HVAC COILS

Sectional Coils

Tight mechanical room or limited space for a large HVAC coil in a service elevator? Don’t let space restraints prevent you from replacing your HVAC coil.

Sectional coils are manufactured into two modular pieces with heavy duty end plates and bolted together in the field.

Tube Material

  • Copper
  • Cupro Nickel 90/10
  • Carbon Steel
  • 304 Stainless Steel
  • 316 Stainless Steel
  • Aluminum

Tube OD

  • 1/2 Inch
  • 3/8 Inch
  • 5/8 Inch
  • 1 Inch

Fin Materials

  • Aluminum
  • Copper
  • 304 Stainless
  • 316 Stainless
  • Carbon Steel
  • Cupro-Nickel 90/10

Header Materials

  • Type L Copper
  • Type K Copper
  • Carbon Steel (Schedule 40 or 80)
  • Cupro-Nickel (Schedule 40)
  • 304 Stainless (Schedule 40 or 80)
  • 316 Stainless (Schedule 40 or 80)
  • Aluminum (Schedule 40)

Casing Materials

  • Aluminum (.063, .090, .100, .125)
  • Carbon Steel (10,12,14,16ga)
  • Copper (.0647 (48oz)
  • Copper (.091 (67oz)
  • Copper (.125 (96oz)
  • Galvanized Steel (8,10,12,14,16,18,20ga)
  • 304 Stainless Steel (10,12,14,16,18,20ga)
  • 316 Stainless Steel (10,12,14,16,18,20ga)

Available Coil Coatings:

  • Epoxy Polmer (E-Coat) with UV Top Coat
  • Epoxy Polmer (E-Coat)
  • Baked on Phenolic
  • Finkote 2
  • Finkote 2 UV Top Coat
  • FinkoteCc
  • FinkoteHp
  • FinkoteZx
  • Heresite
  • Heresite UV
  • ElectroFin
  • ElectroFin UV
  • Blygold Anti-Corrosive
  • Blygold Anti-Microbial
  • Black Poly Coated Fin
  • Iridite
  • Other Options Available Upon Request

Need a replacement HVAC coil ASAP? We can help! We offer 15, 10, and 2-day expedite options. Give us a call at (610) 783-1136 for availability and pricing.

Certified in accordance with AHRI Force-Circulation Air-Cooling and Air-Heating Coils Certification Program which is based on AHRI Standard 410 within the Range of Standard Rating Conditions listed in Table 1 of the Standard.

Certified units may be found in the AHRI Directory at www.ahridirectory.com

OEM & Custom Replacement Sectional Coils

Site Visits

Schedule a Free Site Visit

During our initial site visit, we’ll take measurements, learn about your complete system, diagnose your challenges and recommend a solution. If we don’t have an answer on the spot, we’ll research your need and follow up quickly with a recommendation.



Get a Quote

Contact Us to Get Your Project Started Today

Our seasoned team of experts are here to help you navigate through any heating and cooling system issues. We're not just problem solvers, we're your partners in finding the optimal solution. Reach out to us today for a discussion and a no-obligation quote! Let's make your project our next success story together.
